1.Manufactured from high tensile cast iron, stress relieved for maximum rigidity and long term accuracy. It's the best for continuous production.
2.All bearings are imported from Japan with best properties,precision,long life,effective in ensuring good performance of the press.

3.By using three round pillars structure,can minimize the dynamic friction. Work with forced lubrication to minimize thermal strain life of the frame, upgrade stamping quality and extend service life of the machine.
4.It's more convenient to adjust the die with the die height indicator and the hydraulic locking device.
5.HMI is controlled by microcomputer. Display value and fault monitoring system. It is easy to operate.
6.Balance device for optional to reduce vibration, make press more precision and stable.

•
•
•

ModeI	FC-85
Capacity	85	Ton
Stroke of slide	30   40   50	mm
Maximum SPM	500 450 400	spm
Minimum SPM	100 100 100	spm
Die-Height	360 355 350	mm
Bolster area	1000*600	mm
Slide area	580*450	mm
Slide Adjustment	30	mm
Bed Opening	800(on）*600（Under the）*180（wide）	mm
Motor	15	hp
Net Weight	12000	kg
Accuracy	OptionJIS/JIs Special	grade
