1.Manufactured from high tensile cast iron, stress relieved for maximum rigidity and long term accuracy. It's the best for continuous production.
2.All bearings are imported from Japan with best properties,precision,long life,effective in ensuring good performance of the press.

3.By using three round pillars structure,can minimize the dynamic friction. Work with forced lubrication to minimize thermal strain life of the frame, upgrade stamping quality and extend service life of the machine.
4.It's more convenient to adjust the die with the die height indicator and the hydraulic locking device.
5.HMI is controlled by microcomputer. Display value and fault monitoring system. It is easy to operate.
6.Balance device for optional to reduce vibration, make press more precision and stable.

•
•
•
•
•
•

ModeI	FC-25
Capacity	25	Ton
Stroke of slide	20   25      30  40	mm
Maximum SPM	900 850    800 700	spm
Minimum SPM	200 200    200 200	spm
Die-Height	215 212.5 210 205	mm
Bolster area	600*300	mm
Slide area	300*210	mm
Slide Adjustment	30	mm
Bed Opening	500(on）*300（Under the）*100（wide）	mm
Motor	5	hp
Net Weight	3000	kg
Accuracy	OptionJIS/JIs Special	grade
